Absima Brushless ESC "Thrust A8 ECO" 120A 1:8 Waterproof (AB2110008)

ProgrammaBLe sensorless brushless speed controller (ESC)

Multiple protecting features like low voltage cut-off protection, over-heating protection and throttle signal lose protection. Easy programmed with the set button.

TECHNICAL SPECIFICATION:
Waterproof 120A ESC incl. cooler
Standard running mode: forward/brake/reverse (programmaBLe: forward/brake; forward/reverse)
Standard LiPo cut-off: 3.0V/cell (programmaBLe: non-protect. / 2.6V / 2.8V / 3.2V / 3.4V)
Overheat protection
Peak amps: 760A
BEC: 6V / 3A (switch mode)
Battery: 6-12 cells NiMH / 2-4S LiPo
Motor limit: 2S @ 6000KV / 3S @ 4000KV / 4S @ 2600KV
Brake foRCe: 75% (programmaBLe)
Resistance: 0.0004 ohm
Standard brake foRCe: 50% (programmaBLe: 25% / 75% / 100% / DisaBLe)
Standard drag brake: 0% (programmaBLe: 5% / 10% / 20% / 40% / 60% / 80% / 100%)
Standard start mode (Punch): Level 5 (programmaBLe: Level 1/2/3/4/6/7/8/9/10)
Motor timing: 18.75
Size (L/W/H): 59,3x38,4x33,6 mm
Weight: 113g
